Potato dryer
The Allround Potato dryer is designed to dry potatoes after washing. This is done by felt rollers. These felt rollers absorb water that comes with the potatoes after washing. In their turn, these felt rollers are wringed out by stainless steel rollers. The machine is equipped with stainless steel plates, to ensure durability of the machine.
Types and specifications
DR 60-10
| Total width machine | 2000 mm |
| Length of rollers | 600 mm |
| Number of rollers | 10 |
DR 100-12
| Total width machine | 2500 mm |
| Length of rollers | 1000 mm |
| Number of rollers | 12 |
DR 100-17
| Total width machine | 2700 mm |
| Length of rollers | 1000 mm |
| Number of rollers | 17 |
DR 140-17
| Total width machine | 1940 mm |
| Length of rollers | 1400 mm |
| Number of rollers | 17 |
Options
By-pass
In an Allround integrated line, not all products are to be dried. For this reason, Allround can equip the machine with a by-pass belt which is mounted on the frame of the machine. In this case, the machine is equipped with wheels to make sure the switch between drying and not drying the produce can take place rapidly.
Estimated capacity (tons/hour)
| DR 60-10 | DR 100-12 | Dr 140-17 | |
|---|---|---|---|
| Potatoes | 6 | 10 | 20 |
